Italian Distributors of TELEMED, UAB.

Easy-to-use ultrasound scanners that deliver exceptional image quality, whether you’re using a PC, tablet, or smartphone.

Portable Ultrasound Solutions

ArtUs

SmartUs

MicrUs

MicrUs Pro

 ArtUs Compact

ArtUs

HIGH-END PORTABLE ULTRASOUND

Powerful and compact portable ultrasound scanner with Doppler technology. It supports high-density and high-frequency probes, offering detailed and rich images.

Models
ArtUs EXT-1H: one probe port
ArtUs EXT-2H: two probe ports
Imaging Modes
  • B, B+B, 4B, B+M, M
  • B live+B live (two live simultaneous B-streams from two connected transducers), ArtUs EXT-2H only

B-mode:

  1. B-steer for linear probes
  2. Compound for linear and convex probes
  3. Virtual convex for linear probes
  4. Expanded view angle for convex probes
  • Color Doppler (CFM)
  • Power Doppler (PDI)
  • Directional Power Doppler (DPDI)
  • Pulsed Wave Doppler (PWD)
  • B+PWD (Duplex)
  • B+CFM/PDI/DPDI+PWD (Triplex)
  • Inverted Tissue Harmonic Imaging (ITHI)
  • Tissue Harmonic Imaging (THI)
  • Parallel beam forming
  • Beamformed RF data access through SDK library and set of research software (Python, MATLAB, LabView)



Connectivity
  • USB 3.0
Transducers

Multi-frequency transducers from 1.5 to 18.0 MHz.
Automatic recognition of the transducer

  • Linear
  • Convex
  • Microconvex
  • Phased Array sectorial

Scanning depth: 2 – 40 cm

Ultrasound software
  • Echo Wave II scanning software / Echo Wave II touch GUI (Windows 32/64 bit)

Free downloadable updates.

Research and Development Tools

Hardware tools:

  • I/O Module – optional modules for synchronizing the scanner with other signals or instruments such as ECG, EMG, EEG.
  • RF Module –  optional module that allows to receive RF data in real-time

Software tools:

  • SDK – Software Developement Kit (available with agreement).
  • Real-time imaging for the research (DLL) – allows to call TELEMED SDK functions to perform real-time ultrasound image data acquisition and imaging from the other programming platforms such as MATLAB, Python etc.
  • ArtUs Synchronisation Package – utility for configuring of ArtUs synchronisation input/output signals
  • ArtUs RF Data Control for C++ – control majority of ultrasound scanning parameters, receive RF data in real-time and record RF data to file
  • ArtUs RF Data Control for Python, MATLAB and LabVIEW – control majority of ultrasound scanning parameters, receive RF data in real-time and record RF data to file
  • ArtUs RF Tools Package – RF tools, MATLAB scripts for import and revision of annotated RF data offline. Collection of scripts illustrating conventional RF signal processing steps, which are typically used in the B mode image formation engine is provided as well.
  • Python scripts package – Python RF data viewer (GUI) for import and review of annotated RF data offline.
Power supply
  • External power supply, 100-240V AC, 50-60 Hz
Size and weight

ArtUs EXT-1H:
aluminium enclosure
dimensions W x D x H, mm: 136 x 200 x 34
weight, kg: 0.77

ArtUs EXT-2H:
aluminium enclosure
dimensions W x D x H, mm: 140 x 204.5 x 62
weight, kg: 1.12

SmartUs

HIGH-END PORTABLE ULTRASOUND

Portable ultrasound scanner with continuous doppler technology. Lightweight and compact, it ensures reliability, accuracy and rapid results to provide the best quality in health care.

Models
SmartUs EXT-1M: one probe port
SmartUs EXT-3M: three probe ports
Imaging Modes
  • B, B+B, 4B, B+M, M

B-mode:

  1. B-steer for linear probes
  2. Compound for linear probes
  3. Trapezoid for linear probes
  • Color Doppler (CFM)
  • Power Doppler (PDI)
  • Directional Power Doppler (DPDI)
  • Pulsed Wave Doppler (PWD)
  • Continuous Wave Doppler (CW) – optional
  • B+PWD (Duplex)
  • B+CFM/PDI/DPDI+PWD (Triplex)
  • High Pulse Repetition Frequency (HPRF)
  • Tissue Harmonic Imaging (THI)
Connectivity
  • USB 2.0 & 3.0
Transducers

Multi-frequency transducers from 1.5 to 18.0 MHz.

  • Linear
  • Convex
  • Microconvex
  • Phased Array

Scanning depth: 2 – 30 cm

Automatic recognition of the transducer

Ultrasound software
  • Echo Wave II scanning software / Echo Wave II touch GUI (Windows 32/64 bit)

Free downloadable updates.

Research and Development Tools

Hardware tools:

  • I/O Module – optional modules for synchronizing the scanner with other signals or instruments such as ECG, EMG, EEG.

Software tools:

  • SDK – Software Developement Kit (available with agreement).
  • Real-time imaging for the research (DLL) – allows to call TELEMED SDK functions to perform real-time ultrasound image data acquisition and imaging from the other programming platforms such as MATLAB, Python etc.
  • SmartUs synchronisation utilities – utility for configuring SmartUs synchronisation port
Power supply
  • external power supply, 100-240V AC, 50-60 Hz
Size and weight

SmartUs EXT-1M:
aluminium enclosure
dimensions W x D x H, mm: 54 x 220 x 158
weight, kg: 1.3

SmartUs EXT-3M:
aluminium enclosure
dimensions W x D x H, mm: 213 x 155 x 90
weight, kg: 2.0

Micrus

PORTABLE ULTRASOUND

MicrUs is the portable solution for high quality ultrasound scans, anywhere. With its pocket size, USB power supply and advanced imaging techniques, it ensures detailed images for various applications

Models

MicrUs EXT-1H: one probe port

Imaging Modes
  • B, B+B, 4B, B+M, M

B-Mode:

  1. B-steer for 40mm or less linear probes
  2. Compound for 40mm or less linear probes
  3. Trapezoid for 40mm or less linear probes
  • Pulsed Wave Doppler (PWD)
  • B+PWD (Duplex)
Connectivity
  • USB 2.0 & 3.0
Transducers

Multi-frequency transducers from 2 to 15.0 MHz – Automatic transducer recognition

  • Linear
  • Convex
  • Microconvex

Duo Probe: multi-frequency probe with dual transducers for two simultaneous scans *custom made probe

Scan depth: 2-31 cm depending on the probe used.

Ultrasound software
  • Echo Wave II scanning software / Echo Wave II touch GUI (Windows 32/64 bit)
  • Echo Wave A (Android)

Free downloadable updates.

    Research and Development Tools

    Hardware tools:

    • I/O Module – optional modules for synchronizing the scanner with other signals or instruments such as ECG, EMG, EEG.

    Software tools:

    • SDK – Software Developement Kit (windows/android) (available with agreement).
    • Real-time imaging for the research (DLL) – allows to call TELEMED SDK functions to perform real-time ultrasound image data acquisition and imaging from the other programming platforms such as MATLAB, Python etc.
    • MicrUs synchronisation utilities – utility for configuring MicrUs synchronisation port
    Power supply
    • directly from USB port (if connected to USB 3.0)
    • external power supply, 100-240V AC, 50-60 Hz (if connected to USB 2.0)
    Size and weight
    • MicrUs EXT-1H:
      aluminium enclosure
      dimensions W x D x H, mm: 106 x 105 x 21
      weight, kg: 0.26

    Micrus Pro

    HANDHELD ULTRASOUND

    MicrUs Pro is a handheld ultrasound scanner that provides clear, high-definition with your smartphone, tablet or PC (Windows/Android).

    Models

    MicrUs Pro-L40S: Linear USB Probe

    MicrUs Pro-C60S: Convex USB Probe

    Imaging Modes
    • B, B+B, 4B, B+M, M

    B-Mode:

    1. B-steer for 40mm linear probe (MicrUs Pro-L40S)
    2. Compound for 40mm linear probe (MicrUs Pro-L40S)
    3. Trapezoid for 40mm linear probe (MicrUs Pro-L40S)
    • Pulsed Wave Doppler (PWD)
    • B+PWD (Duplex)
    Connectivity
    • directly from USB-C port
    Transducers

    Multi-frequency transducers – Automatic transducer recognition

    MicrUs Pro-L40S:

    • 5.0 – 12.0 MHz
    • Lenght 40mm

    MicrUs Pro-C60S:

    • 2.0 – 5.0 MHz
    • Radius 60mm

    Scan depth: 2-23 cm depending on the probe used.

    Ultrasound software
    • Echo Wave II scanning software / Echo Wave II touch GUI (Windows 32/64 bit)
    • Echo Wave A (Android)

    Free downloadable updates.

      Research and Development Tools

      Software tools:

        • SDK – Software Developement Kit (windows/android) (available with agreement).
        • Real-time imaging for the research (DLL) – allows to call TELEMED SDK functions to perform real-time ultrasound image data acquisition and imaging from the other programming platforms such as MATLAB, Python etc.
      Power supply
      • directly from USB-C port
      Size and weight

      MicrUs Pro-L40S:
      plastic enclosure
      weight: 230g

      MicrUs Pro-C60S:
      plastic enclosure
      weight: 260g





      Advanced Imaging Software.

      The evolution of Telemed software is continuous, always looking for innovative solutions to improve the ultrasound experience.

      Echo Wave A

      ANDROID

      Echo Wave II

      TOUCH GUI

      Echo Wave II

      STANDARD GUI

      Experience the Power of Advanced Ultrasound Technology

      From ultra-compact, handheld models for applications such as point-of-care, emergency medicine, and home care to advanced systems for research and development of new diagnostic modalities.

      The systems are preconfigured for the integration with other imaging systems and hospital management software, facilitating data sharing and analysis.

      Telemed Quality

      Seamless integration

      Flexible customization

      Transducers for specific applications

      Those ultrasound systems support a wide variety of probes with high crystal density and a broad spectrum of frequencies, providing high-definition images with a wide dynamic bandwidth for accurate and comprehensive analysis.

      Because Every Detail Matters.

      Equipped with advanced technology and cutting-edge features, the ultrasound systems offer exceptional sharpness, precision, and clarity in every scan.

      Intuitive, modular, ready-to-use research tools for optimized setup time.

      The ultrasound scanners offers researchers powerful tools, enabling breakthrough discoveries.
